Home/ Sewer Repair/ Solutions/ Trenchless Pipe Bursting

SOLUTION · CHARLOTTE, NC

Trenchless Pipe Bursting that replaces your sewer line without trenching.

Trenchless Pipe Bursting pulls a brand-new, full-diameter HDPE pipe through your failing old one, simultaneously shattering the deteriorated pipe outward. No open trench. No disrupted yard. Most residential runs complete in a single day.

Call About Trenchless Pipe Bursting: 336-477-3218 Request a Free Estimate

Tell us what's going on

The first call costs nothing. Flat-rate pricing. No upsells, ever.

We'll call you back within one business hour. No automated systems.

COMMON REASONS

When Trenchless Pipe Bursting is the right call.

Some sewer lines are too far gone for a liner. Trenchless Pipe Bursting is the no-dig answer when CIPP isn't an option. Four situations show up on nearly every job.

Common Trenchless Pipe Bursting situations:

Trenchless Pipe Bursting for fully collapsed pipe

When the host pipe has lost its shape, CIPP can't cure inside it. Trenchless Pipe Bursting shatters the old pipe outward and pulls new HDPE through, with no shape required.

Trenchless Pipe Bursting for severely offset joints

Offset joints beyond the bridging range of a liner require a full-replacement solution. Trenchless Pipe Bursting threads a continuous new pipe through the entire run regardless of offsets.

Trenchless Pipe Bursting for upsizing undersized pipe

Need to jump from a 4-inch to a 6-inch main? Trenchless Pipe Bursting is the only no-dig method that can actually increase pipe diameter as it replaces the old line.

Trenchless Pipe Bursting for clay or cast-iron under hardscape

When the failing line runs under a driveway, patio, or mature trees, Trenchless Pipe Bursting replaces it with zero surface disruption between the two access pits.
Collapsed clay sewer pipe, a prime candidate for Trenchless Pipe Bursting.
Excavated collapsed pipe that could have been replaced with Trenchless Pipe Bursting sooner.

CATCH PROBLEMS EARLY

Why Trenchless Pipe Bursting is a timing decision.

The window for Trenchless Pipe Bursting stays open as long as the line has a passable bore. Waiting until sewage backs up into the home removes no-dig options and drives costs up sharply.

Watch for these Trenchless Pipe Bursting triggers:

  • Trenchless Pipe Bursting works before the line goes completely dry
    Once raw sewage breaks through the surface or floods the basement, open excavation becomes the only path. Trenchless Pipe Bursting requires a bore, even a partial one, to thread through.
  • Trenchless Pipe Bursting stops slow yard contamination
    Leaking sewer pipe deposits bacteria and nitrates into the soil over months. A scheduled Trenchless Pipe Bursting job ends the contamination before it reaches a well or storm drain.
  • Trenchless Pipe Bursting preserves mature trees
    Roots that have breached the pipe zone often sit right under mature trees. Open-cut excavation kills those trees. Trenchless Pipe Bursting uses only two access pits, so the trees stay.
  • Trenchless Pipe Bursting avoids driveway replacement costs
    Replacing a 40-foot driveway after excavation adds real cost to the bill. Trenchless Pipe Bursting eliminates that cost entirely.

SERVICE PROCESS

How our Trenchless Pipe Bursting process holds up.

A Trenchless Pipe Bursting install is precise, fast, and leaves behind a durable HDPE pipe. Four standards make every LiningWorks pipe bursting job consistent.

Trenchless Pipe Bursting starts with full HD camera scope

We map the entire run on camera first: diameter, material, depth, offset, and defect locations. That data drives the bursting-head spec and the HDPE pipe order.

Trenchless Pipe Bursting uses minimal access pits only

We dig two small access pits: one entry, one exit. No open trench. Everything between those pits stays undisturbed during the Trenchless Pipe Bursting pull.

Trenchless Pipe Bursting pulls seamless HDPE pipe through

A hydraulic bursting head fractures the old pipe outward while a continuous HDPE pipe follows immediately behind. No joints, no glue, no future root infiltration points.

Trenchless Pipe Bursting is verified with a post-install scope

After the pull, we run a camera from cleanout to city connection. You watch the new HDPE pipe on screen and receive both the before and after footage on a USB drive.
LiningWorks crew setting up a Trenchless Pipe Bursting pull on a Charlotte residential job.

SIMPLE PROCESS

The Trenchless Pipe Bursting process, step by step.

Same five-step Trenchless Pipe Bursting sequence on every residential job, whether the run is 28 feet or 280 feet. Here's how it actually works.

Camera scope before any Trenchless Pipe Bursting work.
Step 1

Camera-scope the full run before any Trenchless Pipe Bursting work.

High-resolution sewer camera maps cracks, collapses, offsets, and the city-tap connection. Trenchless Pipe Bursting specs (head size, HDPE diameter, pull length) all come from this footage.

Schedule a consultation
Minimal access pits dug for Trenchless Pipe Bursting.
Step 2

Excavate two minimal access pits for the Trenchless Pipe Bursting pull.

Entry pit at the cleanout end, exit pit at the city connection. Everything between is untouched. Most Trenchless Pipe Bursting access pits are 3×3 feet, a fraction of open-cut excavation.

Schedule a consultation
Bursting head and HDPE pipe staged for Trenchless Pipe Bursting.
Step 3

Thread the Trenchless Pipe Bursting head through the old pipe.

A steel cable is run through the old pipe. The bursting head and trailing HDPE pipe are attached at the entry pit. The hydraulic winch is staged at the exit pit, ready to pull.

Schedule a consultation
Close-up of a cured-in-place epoxy pipe liner interior.
Step 4

Pull the Trenchless Pipe Bursting head: old pipe shatters, new pipe follows.

The hydraulic winch pulls the bursting head through the old pipe, fracturing it outward while the new HDPE pipe follows directly behind. The entire Trenchless Pipe Bursting pull typically takes one to two hours.

Schedule a consultation
Camera verify the finished Trenchless Pipe Bursting install.
Step 5

Camera-verify the finished Trenchless Pipe Bursting install end to end.

We run a post-install camera scope from cleanout to city tap. You watch the smooth, jointless HDPE pipe on screen, sign off, and leave with both videos. Backfill and surface restoration follow immediately.

Schedule a consultation

TRENCHLESS PIPE BURSTING IN ACTION

See Trenchless Pipe Bursting work on a real Charlotte job.

More Pipe Bursting videos on YouTube →
WHAT HOMEOWNERS SAY

Real results. Real reviews.

WHY HOMEOWNERS TRUST US

What you get when LiningWorks runs your Trenchless Pipe Bursting.

Trenchless Pipe Bursting is a precision job. We treat every pull the way we'd want it done on our own homes.

NC-licensed Trenchless Pipe Bursting crew

NC Plumbing License #16952. Every Trenchless Pipe Bursting pull is run by the same licensed brothers and is never subcontracted.

Same-week Trenchless Pipe Bursting scheduling

Most Trenchless Pipe Bursting jobs in Charlotte are on the calendar within the same week. One-day install for most residential runs.

Flat-rate Trenchless Pipe Bursting pricing

You see the camera footage and the flat-rate quote before any Trenchless Pipe Bursting work begins. No hourly billing, no surprise add-ons at the end.

Workmanship guarantee on every Trenchless Pipe Bursting job

Every Trenchless Pipe Bursting install carries our written workmanship guarantee.
LiningWorks brothers in front of Trenchless Pipe Bursting service trucks.

FAQ

Trenchless Pipe Bursting: Frequently Asked Questions

Short, honest answers, the same way we'd explain it on the phone.

Trenchless Pipe Bursting is a no-dig pipe replacement method that fractures the existing sewer pipe outward while simultaneously pulling a new, seamless HDPE pipe through the same path. Two small access pits replace the need for an open trench.

Most residential Trenchless Pipe Bursting jobs in Charlotte complete in a single day. The actual burst pull takes one to two hours; camera scoping, pit excavation, and backfill make up the rest of the day.

Trenchless Pipe Bursting typically costs less in total than open-cut excavation once you account for driveway, landscaping, and surface restoration. The pipe material is slightly more, but the avoided surface repairs more than offset it.

Yes. Trenchless Pipe Bursting can increase pipe diameter, commonly from 4-inch to 6-inch, because the bursting head displaces the old pipe outward, creating room for a larger replacement.

Trenchless Pipe Bursting requires a passable bore through the old pipe. If the line has no bore at all, or runs through rock with no displacement path, open-cut excavation or an alternative trenchless method may be needed.
